CE1250-8 (125 Ton Hydraulic Mining Excavator)

Diesel engine emissions meet the latest environmental regulations. Equipped with top-brand hydraulic components for maximum reliability and performance. This excavator can also be configured with an electromotor, offering zero emissions, low noise, reduced operating costs, and adaptability to a wide range of temperatures. Dual-power options (diesel + electric) combine the benefits of electric efficiency with diesel mobility. H-type disassembled undercarriage ensures simple structure, high torsion-resistance, stability, and compliance with road, rail, and sea transport standards.

Diesel engine emmissions conform to the latest environmental regulations.

It is configured with the world famous brand hydraulic components. The main hydraulic components, such as pumps and valves, adopt international famous brands to ensure the high quality and high reliability of the machine. The hydraulic hose adopts the international famous brand, and its excellent performance guarantees the high reliability of machine.

The excavator of this tonnage can also be configured with an electromotor which has the uique advantages of zero emission, low noise, low operation & maintenance cost, good adaptability to a wide range of ambient temperatures. In addition, this tonnage excavaotor can also be configured with dual powers both by diesel engine and electromotor, it share the electric excavator’s unique advantage and diesel excavator’s mobile convenience.

H-type disassembled undercarriage featured as simple structure and high torsion-resistance, more stable and reliable. H-type disassembled undercarriage is accordance with all standards for road, railway and sea transportation.

SPECIFICATIONS

No.

Item

Unit

Data

Shovel

Backhoe

1

Machine weight

t

121-125

118-124

2

Bucket capacity

Standard

m3

7.0

7.0

Range

m3

5.5-8.0

4.0-7.0

3

Diesel engine

Model



QSK23-C760

Power/Speed

kW/rpm

567/1800

Fuel tank capacity

L

1300

4

Hydraulic system

Type



Three pumps and three loops,   limit load variable system

Max. operating pressure

MPa

32

Max. flow rate

L/min

3×533

Control type



Hyd. pilot control

Hydraulic oil tank capacity

L

900

5

Performance data

Slewing speed

r/min

5.2

Travel speed

km/h

2.4

Max. traction force

KN

661

Gradeability

%

52

Ground pressure

MPa

0.127

Cycle time of working

s

22

6

Working data

Boom length

mm

5300

7800

Stcik length

mm

3800

3400

Max. digging reach

mm

11402

14040

Max. digging depth

mm

3737

7946

Max. digging height

mm

12606

13310

Max. dumping height

mm

9055

8381

Max. digging force of stick

KN

587

509

Max. breakout force of bucket

KN

640

411
